High-Accuracy VK-8300 Thickness Gauge for Industrial Quality Control

The VK-8300 Coating Thickness Gauge is a professional device designed for precise measurement of various material thicknesses. It is suitable for measuring the thickness of metals, plastics, ceramics, glass, and other good conductors of ultrasonic waves. The instrument offers high accuracy and reliability, making it widely used in industries such as oil, chemical, metallurgy, shipbuilding, aviation, aerospace, and more, meeting stringent requirements across these sectors.
The VK-8300 Coating Thickness Gauge, with its outstanding performance and multifunctionality, is an essential inspection tool in many industries. Whether for quality control during production or final product inspection, it provides efficient and accurate data support.

Coating Thickness Gauge VK-8300

Product Overview

The VK-8300 Coating Thickness Gauge, with its outstanding performance and multifunctionality, is an essential inspection tool in many industries. Whether for quality control during production or final product inspection, it provides efficient and accurate data support.

Application Areas:

· Industrial Material Inspection: Suitable for thickness measurement of metals, plastics, ceramics, glass, and other materials.

· Manufacturing Industries: Used for quality control and process monitoring in oil, chemical, metallurgy, shipbuilding, aviation, aerospace, and other fields.

Product Features:

· Wide Measurement Range: From 1.00mm to 300mm, suitable for various applications.

· High-Precision Measurement: Provides different measurement accuracies based on the thickness range to ensure accurate and reliable data.

· Rapid Measurement: Supports high-speed measurement, enhancing work efficiency.

· Large Data Storage: Stores up to 1,000 sets of data for easy data management and analysis.

· Durable Battery: Equipped with a built-in 3.7V lithium battery with a capacity of 2,200mAh, providing convenient charging and long usage time.

· Intelligent Energy Saving: Features automatic power-off function, allowing customization of shutdown times to conserve energy.

· Lightweight and Portable: Compact design and lightweight structure make it easy to carry and use on-site.

Technical Specifications

Model	VK-8300
Sensor Type	5 MHz
Measurement Range	1.00-300 mm
Accuracy	H < 10 mm: ±0.1 mm H ≥ 10 mm: ±0.1 + 1%H H < 75 mm: ±0.05 mm H < 75 mm: ±0.01 + 0.5%H H ≥ 75 mm: ±0.1 + 1%H
Measurement Rate	1000-9999 m/s
Data Storage	1,000 Sets
Power Supply	3.7 V Lithium Battery (2,200 mAh)
Auto-Off	10 minutes / 30 minutes / 1 hour
Charging Time	2-3 Hours
Net Weight	320 g
Product Dimensions	222 × 80 × 46 mm
Packaging Dimensions	270 × 220 × 80 mm
Packaging Weight	780 g
