VK-700 Multi-Parameter Air Quality Detector - Comprehensive Indoor Air Monitoring"

VK-700 Air Quality Detector

Product Introduction

The VK-700 Air Quality Detector is a high-performance, multi-functional environmental monitoring device designed to provide users with accurate and reliable air quality data. This instrument employs advanced laser infrared scattering modules, laser infrared (NDIR) technology, semiconductor sensing technology, and integrated capacitive humidity and gap-type temperature sensors to comprehensively monitor various pollutants in indoor air. The TC-700 is suitable for monitoring carbon dioxide in industrial and agricultural environments, as well as for air quality monitoring in homes, offices, and public spaces.

The VK-700 Air Quality Detector, with its outstanding technical performance and broad range of applications, is an ideal choice for environmental monitoring. Both professionals and ordinary users can easily obtain accurate environmental quality data using this instrument, thereby better protecting health and enhancing quality of life.

Application Areas

· Industrial and Agricultural Environments: Factories, workshops, greenhouses, cleanrooms, etc., for carbon dioxide monitoring.

· Residential and Office Spaces: Homes, villas, office buildings, meeting rooms, classrooms, etc., for ventilation control and environmental quality monitoring.

· Public Places: Hotels, exhibition halls, hospitals, malls, bars, restaurants, airports, train stations, entertainment venues, cinemas, etc., for ventilation control and environmental quality monitoring.

Key Features

· Multi-Parameter Monitoring: Simultaneously monitors CO2, PM2.5, PM10, formaldehyde, volatile organic compounds (VOCs), temperature, humidity, and air quality index.

· High Precision: Particulate matter concentration accuracy reaches ±10% (@100~500 μg/m³), ±10 μg/m³ (@0~100 μg/m³), and CO2 concentration accuracy is ±3% of readings or ±40 PPM.

· Wide Measurement Range: Particulate matter concentration: 0-1000 μg/m³; CO2 concentration: 370-10000 PPM; formaldehyde concentration: 0-1.000 mg/m³; VOC concentration: 0-2.000 mg/m³.

· High Resolution: Particulate matter concentration: 1 μg/m³; CO2 concentration: 1 PPM; formaldehyde and VOC concentration: 0.001 mg/m³.

· Efficient Counting Efficiency: 50% @0.3 μm and 98% @≥0.5 μm.

· Portable Design: Lightweight and portable, weighing only 225 g, making it easy to carry.

· Long Battery Life: Equipped with a built-in 3.7V rechargeable lithium battery, capacity 2200 mAh, charging time is only 2-3 hours.

Technical Specifications
